Shower Braille Sign – Blue/Silver
$30.00
Shower Braille Sign – Blue/Silver Features
- 180×180
- Tactile Braille Sign with at least 30% luminance -contrast with the background
- Comes with double-sided tape for easy installation
- UV Protected
- Solid and Thick PVC
- Internationally recognized symbols
- Complies with Australian Standards AS1428 / Building Code of Australia (Section D3.6)/ Design for Access and Mobility
Description
Shower Braille Sign – Blue/Silver
PLACEMENT OF SIGNS
- Signs must be located not less than 1200mm and not higher than 1600mm above the floor or ground surface.
- Signs with single lines of characters must have the line of tactile characters not less than 1250mm and not higher than 1350mm above the floor or ground surface.
- Signs identifying rooms containing features or facilities listed in D3.6 must be located:
- on the wall on the latch side of the door with the leading edge of the sign located between 50mm and 300mm from the architrave
- in the event of insufficient latch side dimension, a sign may be placed on the non-latch side of the door
- where (1) and (2) is not possible, the sign may be placed on the door itself.
- Signs identifying paths of travel must be placed so they are located directly ahead in the direction of travel.
- Where one wall continues in the direction of travel and the other forms a corner, the sign must be placed on the continuing wall.
TOILET LH/RH HANDING
Toilet signs that include LH and RH are designed to show wheelchair users which way to transfer on to the toilet. Please refer to the image below:
toilet handling sign
